TLSLUS70T3AGRR7
LED Street light
Selectable power : 25W / 40W / 70W
Selectable CCT : 2200K / 3000K / 4000K
Light output : 25W : 3 000 lm / 40W : 4 800 lm / 70W : 8 400 lm
Selectable CCT : 2200K / 3000K / 4000K
Light output : 25W : 3 000 lm / 40W : 4 800 lm / 70W : 8 400 lm





Product information
Description
Model
TLSLUS70T3AGRR7
DLC ID
N/A
Power (W)
25W / 40W / 70W
Input Voltage (V)
120-347V, 50/60Hz
Efficacy
120 lm/W
Power Factor (PF)
>0.9
Surge protection
10 kv
Total harmonic distortion
<15%
Dimmable
0-10V
CRI
>70
CCT
2200K / 3000K / 4000K
Beam angle
Type III
Light Output
IP Rating
Wet locations
Material
Aluminum
Lens
PC
Net weight
4 kg
Dimensions
Operating Humidity
10% ~ 90%
Operating Temperature
-40°C ~ 50°C
